Thread: Fuse box diagram

  1. #1

    Array
    Status
    Offline
    Join Date
    12-02-2013
    Posts
    2
    Location

    Phoenix, AZ
    Vehicle

    1994 Mitsubishi Mighty Max
    Engine

    4G15

    Fuse box diagram

    Could anybody with a circa 1994 Mighty Max be so kind as to send a picture (or diagram) of the fuse block? The cover is long gone, and most of the fuses have been pulled out (don't ask why!). I need to know the amperage for each fuse. Thanks!

  2. #2

    Array
    Status
    Offline
    Join Date
    04-10-2011
    Posts
    256
    Location

    WA
    Vehicle

    1990 Mitsubishi Mighty Max
    Engine

    6G72
    Click image for larger version.

Name:	image.jpg
Views:	1445
Size:	66.2 KB
ID:	7271. This is from my 94.
    1990 MM 4x4 3.0
    1991 MM 4x4 3.0 Diamonte
    1994 MM 2wd (work in progress)

  3. #3

    Array
    Status
    Offline
    Join Date
    04-10-2011
    Posts
    256
    Location

    WA
    Vehicle

    1990 Mitsubishi Mighty Max
    Engine

    6G72
    Click image for larger version.

Name:	image.jpg
Views:	1264
Size:	74.9 KB
ID:	7272. Maybe this one isClick image for larger version.

Name:	image.jpg
Views:	1264
Size:	74.9 KB
ID:	7272 clearer.
    1990 MM 4x4 3.0
    1991 MM 4x4 3.0 Diamonte
    1994 MM 2wd (work in progress)

  4. #4

    Array
    Status
    Offline
    Join Date
    12-02-2013
    Posts
    2
    Location

    Phoenix, AZ
    Vehicle

    1994 Mitsubishi Mighty Max
    Engine

    4G15
    Thanks so much! That's exactly what I need. I knew this was the right place to ask!

  5. #5

    Array
    Status
    Offline
    Join Date
    05-05-2016
    Posts
    1
    Location

    Nashville, TN
    Vehicle

    1989 Dodge Ram 50
    Engine

    I.D.K.?
    Would this be the same for a 1989 Ram 50 2.0?

  6. #6



    Array
    Status
    Offline
    Join Date
    03-26-2011
    Posts
    1,512
    Location

    Vacaville, CA
    Vehicle

    1989 Mitsubishi Mighty Max
    Engine

    4G63-T
    Yes basically the same minus a few added fuses at the end(power acc)
